If you tried setting up an IPv6-capable VPN on a VPS provider that gave you an IP range to play with, perhaps a /64 or larger, you would want to assign some of the IPv6 addresses you have to your clients. In this post, we suppose that you have the range 2001:db8::/64.

This should be a simple process: enable the sysctl option net.ipv6.conf.all.forwarding to 1 (or whatever the equivalent is on your system), use DHCPv6 or SLAAC to assign the addresses to the clients, and then your client should have working IPv6.

The Problem

Unfortunately, this is not so simple. Most VPS providers are not actually routing the entire subnet 2001:db8::/64 to you. Rather, they just connect a number of VPSes onto the same virtual Ethernet network and rely on the Neighbour Discovery Protocol (NDP) to find the router.

I have always wanted to make this website load fast everywhere in the world, despite the server being in Montréal, Canada, without investing heavily. It shouldn’t be hard: after all, it is just a bunch of static files, generated with Jekyll.

Cloudflare brings a free CDN. You can set a page rule to aggressively cache your website on their CDN edge nodes, allowing your site to load as if it is hosted locally, even if you are half a world away.

There is just a little problem: how do you efficiently purge the cache when you update your site? It is quite easy to purge the entire cache on Cloudflare, but that is rather inefficient: most of your assets probably did not change, and now they will all have to be fetched again.

Today I decided to tackle this problem by creating purge-static, a tool designed to purge your CDN cache. It can purge your Cloudflare cache for you. You can get started by running pip install purge-static.

Recently, I had to deal with an issue on DMOJ, where a page displaying 100 out of around a million elements took over 10 seconds to load. Naturally, I started investigating the issue.

(Note: DMOJ uses MariaDB, but the same problem, as well as the eventual solution, should work the same on MySQL as well.)

The first course of action, of course, was to see what the database was trying to do, by running an EXPLAIN query. For those of you who don’t know, if you have a query of the form SELECT x FROM y WHERE z, running EXPLAIN SELECT x FROM y WHERE z would show what the query is doing, without actually executing the query.

A quick look at the EXPLAIN output showed that MariaDB first did a filter on a 2000 row table, and then joined in the table with a million elements. Then, the 100 wanted rows were filtered out. This query plan was quite horrifying.

On Windows, using Python 2’s subprocess module to launch a process with a unicode command line that is not strictly from the currently active ANSI code page (i.e. encoding mbcs) will be mangled. All characters that cannot be encoded by mbcs will, in fact, be replaced with ?.

Obviously, this is can be resolved by switching to Python 3, but sometimes, converting to Python 3 is not yet an option. A terrifying prospect in 2018, but a problem nonetheless.

I present the module uniprocess, which defines its custom version of Popen and friends to work around the problem. I hope it proves useful to you.

I personally prefer the nginx.org packages for nginx over the ones that comes with Debian. They are usually newer and have a more sane amount of dependencies. I also prefer the conf.d system over the sites-available and sites-enabled system.

The main challenge in installing these packages on Debian is the trouble you have to go through to get the PGP keys and sources.list set up. nginx.org does not present a good setup script. This has become a repetitive and annoying experience, so I present a series of commands to set it up quickly.

For stable:

curl https://nginx.org/keys/nginx_signing.key | sudo apt-key add -
(codename="$(dpkg --status tzdata | grep Provides | cut -f2 -d'-')"; echo; for deb in deb deb-src; do echo $deb http://nginx.org/packages/debian/ "$codename" nginx; done) | sudo tee -a /etc/apt/sources.list
sudo apt update && sudo apt install nginx

For mainline:

curl https://nginx.org/keys/nginx_signing.key | sudo apt-key add -
(codename="$(dpkg --status tzdata | grep Provides | cut -f2 -d'-')"; echo; for deb in deb deb-src; do echo $deb http://nginx.org/packages/mainline/debian/ "$codename" nginx; done) | sudo tee -a /etc/apt/sources.list
sudo apt update && sudo apt install nginx

Recently, the DMOJ judge codebase has been migrated to Python 3, thanks to the combined efforts of me, Xyene, and kiritofeng. Many issues, such as unicode handling were exposed in the process.

Since Python 2 is still in heavy use, at least in the deployment of the DMOJ judge, compatibility with it must be maintained. This necessitated writing code in such a fashion as to be compatible with both Python 2 and Python 3. The six library has proved tremendously helpful in abstracting away the differences, some of which highly non-trivial.

For example, six.with_metaclass hides away the difference in metaclass use. In Python 2, the __metaclass__ class member defines the metaclass used for the class, while in Python 3, one would specify it as class Class(metaclass=MetaClass). The latter would be a syntax error in Python 2, and the former has no effect in Python 3. six provides a solution that is highly non-obvious and yet works perfectly.

The most frustrating part is unicode-handling. The DMOJ judge was written somewhat sloppily in regards to unicode handling, dealing mostly with bytestrings and raw bytes. With the separation of bytes and str in Python 3, strings in the judge must be turned into either bytes or str on a case-by-case basis. It is decided that source code and program output will be treated as raw bytes, and textual data that are derived from these will be handled as UTF-8.

Most users are probably using Raspbian on their Raspberry Pi 3. However, Raspbian is designed for all Raspberry Pi devices, back to the original Raspberry Pi, which is ARMv6 with an FPU. This does not take advantage of the 64-bit support on the ARMv8 CPU on the Raspberry Pi 3.

Debian has offered ARM64 support for a while, and being the base distribution for Raspbian, is quite similar. Conveniently, there is a pre-built Debian image for Raspberry Pi 3. You can download it and copy it to a SD card, and it should work out of the box.

On Linux, the simple dd command showed on the Debian Wiki works. On other platforms, notably Windows, Etcher is reputed to work well and has an easy interface.

The one flaw with this image is that the WiFi does not work.

Update: The 20180108 image now works with WiFi out of the box. The following instructions are no longer necessary.

ARM is unusual among the processors by having the program counter available as a “general purpose” register. Most other processors have the program counter hidden, and its value will only be disclosed as the return address when calling a function. If you want to modify it, a jumping instruction is used.

For example, on the x86, the program counter is called the instruction pointer, and is stored in eip, which is not an accessible register. After a function call, eip is pushed onto the stack, at which point it could be examined. Return is done through the ret instruction which pops the return address off the stack, and jumps there.

Another example: on the MIPS, the program counter is stored into register 31 after executing a JALR instruction, which is used for function calling. The value in there can be examined, and a return is a register jump JR to that register.

ARM’s unusual design allows many, many ways of returning from functions. But first, we must understand how function calls work on the ARM.

Sometimes, after many attempts, you realized that to complete your mission, you must access private fields, or perhaps change final fields.

There are many reasons imaginable: the accessors copy the entire object before returning, and that takes a very long time, the authors forgot to provide an accessor, the library function is highly inefficient and you need to do better, …

Are you out of luck? Fortunately, no.

As most probably know, DMOJ uses a sandbox to protect itself from potentially malicious user submissions. An overview of the Linux sandbox has been published by my friend Tudor. However, it doesn’t go deep into the implementation details, many of which differ between Linux and FreeBSD.

At its core, the sandbox, cptbox, uses the ptrace(2) API to intercept system calls before and after they are executed, denying access and manipulating results. The core is written in C, hence the name cptbox.

Perhaps the most obvious difference between Linux and FreeBSD is that on Linux, ptrace(2) subfunctions are invoked as ptrace(PTRACE_*), while on FreeBSD, it is ptrace(PT_*). But this difference is rather superficial compared to the significant internal differences.
